CorruJET 170

Highest volume.
Best of both worlds.

Built for customers demanding high volumes with all the capabilities to combine the best of flexo-printing with world-beating digital quality and productivity.

The CorruJET 170 delivers high production volume in excess of 1.5mio sqm per month. Hybrid capabilities utilizing digital printing in combination with flexo towers. Extremely sharp reproduction detail. Food-safe water-based inks to meet current and future regulatory and environmental standards.

Engineered for the highly efficient production of corrugated sheets with top-quality digital printing. Attain perfection with every print.

Our promise to you

This high-quality press is renowned for its durability and reliability. To ensure the highest performance for the foreseeable and untapped future of possibilities.

Our promise to you

This high-quality press is renowned for its durability and reliability. To ensure the highest performance for the foreseeable and untapped future of possibilities.

Meet the CorruJET

Customized shopping baskets
Corrugated fruit tray

Developed specifically for the corrugated industry, the CorruJET 170 is engineered for the highly efficient production of corrugated sheets with top-quality digital printing.

Easy to use

This unique concept for digital direct printing on corrugated board combines the latest technologies and functionalities with simple and intuitive handling.

Exceptional performance

Operating with a maximum production speed of 5,500 sheets/hour, the CorruJET 170 is able to process corrugated boards up to a maximum thickness of 8 mm.

CorruJET 170 Technical Details

Media type	Corrugated board (hard-edge-feed)
Min. sheet size	750 x 520 mm
Max. sheet size	1300 x 1700 mm (CorruJET 170X 1300 x 2800mm)
Min. sheet thickness	1 mm (F-flute)
Max. sheet thickness	8 mm (BC-flute)
Max. stack height	1100 mm
Max. print resolution	1200 dpi
Printing speed	5 500 sheets/h
Colours	4C CMYK (incl. Precoater)
Ink type	Water technology (Ink + Precoater)

All you need

for digital post-printing onto corrugated board

CorruJET 170 Technical Details

Media type	Corrugated board (hard-edge-feed)
Min. sheet size	750 x 520 mm
Max. sheet size	1300 x 1700 mm
Min. sheet thickness	1 mm (F-flute)
Max. sheet thickness	8 mm (BC-flute)
Max. stack height	1100 mm
Max. print resolution	1200 dpi
Printing speed	5 500 sheets/h
Colours	4C CMYK (incl. Precoater)
Ink type	Water technology (Ink + Precoater)

Quick facts

Download our brochure for detailed information

Up to 5,500 sheets/hour
Sheets up to 8mm in thickness
Water-based, food-safe ink
Modular design for four colors
Fuji Dimatix Samba printing heads with variable drop size
Inline Pre-coater and Post-coater
Press control via a flexible Profibus system with touchscreen interface
Integrated remote support and predictive maintenance features

Quick facts

Up to 5,500 sheets/hour
Sheets up to 8mm in thickness
Water-based, food-safe ink
Modular design for four colors
Fuji Dimatix Samba printing heads with variable drop size
Inline Pre-coater and Post-coater
Press control via a flexible Profibus system with touchscreen interface
Integrated remote support and predictive maintenance features

Download our brochure for detailed information
